Small Fragment Plating System

Shaft Screw 3.5mm

Specifications

Shaft Screw 3.5mm

Thread Dia.	3.5mm
Drill Bit for Threaded Hole	2.5mm
Drill Bit for Gliding Hole	3.5mm
Shaft Dia.	3.5mm
Core Dia.	2.4mm
Hexagonal Socket Width	2.5mm
Head Dia.	6.0mm

Code		Length (mm)	Thread Length (mm)
S.S.	Titanium	Length (mm)	Thread Length (mm)
740.12	740.12T	12mm	4
740.14	740.14T	14mm	4
740.16	740.16T	16mm	6
740.18	740.18T	18mm	6
740.20	740.20T	20mm	6
740.22	740.22T	22mm	6
740.24	740.24T	24mm	10
740.26	740.26T	26mm	10
740.28	740.28T	28mm	10
740.30	740.30T	30mm	10
740.32	740.32T	32mm	14
740.34	740.34T	34mm	14
740.36	740.36T	36mm	14
740.38	740.38T	38mm	14
740.40	740.40T	40mm	18
740.45	740.45T	45mm	18
740.50	740.50T	50mm	18
