Mini Fragment Plating System

L- and T- Plate 2.7mm having 3 holes in Shaft & 2 holes in Head

Indications:

Oblique or transverse fractures of metacarpals and metatarsals
Osteotomies and nonunions of metacarpals and metatarsals

Specifications

Features

2 holes in the head and 3 holes in shaft
L and T profile provides additional fixation for head of metacarpals and metatarsals
Allows compression of fracture fragment by eccentric placement of screws
Low profile
Can be contoured to the anatomy of the bone
Minimal soft tissue irritation
Fixed with 2.7 mm cortex screws
Available in both Titanium and Stainless Steel

Profile

Width (W): 7 mm
Hole Spacing (HS): 8 mm

Pin	CODE
Pin	S.S.	Titanium
L-Left	672.31	672.31T
L-Right	672.32	672.32T
L-Oblique	672.33	672.33T
R-Oblique	672.34	672.34T
T-Shaped	672.41	672.41T
