Large Fragment Plating System

Medial Proximal Tibia Bone Plate

Indications:

Proximal tibial plateau fractures
Osteotomy of proximal tibia

Specifications

Features

Designed to sit on medial aspect of proximal tibia
Allows a stable fixation of the small proximal fragments
Preshaped separately for left and right tibia
Oblong hole for accurate placement of plate on bone
Head holes suitable for 6.5 mm cancellous screws and shaft holes accept 4.5 mm cortex screws
Available in both Titanium and Stainless Steel

Profile

Thickness (T): 4.5 mm
Width (W): 13 mm
Hole Spacing (HS): 18 mm

No. of Holes	CODE - Left		CODE - Right
No. of Holes	S.S.	Titanium	S.S.	Titanium
5	655.05L	655.05TL	655.05R	655.05TR
6	655.06L	655.06TL	655.06R	655.06TR
7	655.07L	655.07TL	655.07R	655.07TR
8	655.08L	655.08TL	655.08R	655.08TR
9	655.09L	655.09TL	655.09R	655.09TR
10	655.10L	655.10TL	655.10R	655.10TR
11	655.11L	655.11TL	655.11R	655.11TR
12	655.12L	655.12TL	655.12R	655.12TR
13	655.13L	655.13TL	655.13R	655.13TR
